Description:
Release time:2026-08-19
Views:10

bolt-assembled sheet cement silos are vertical modular powder storage devices. The silo body is assembled on-site from prefabricated steel plate flanges using high-strength bolts. Specifically designed to solve the challenges of transporting oversized and overweight materials for overseas exports, it primarily stores dry bulk powders such as cement, fly ash, and mineral powder. It is widely used in conjunction with fixed and mobile concrete mixing plants. With a tonnage range of 50T–500T, it is the most popular silo type for overseas infrastructure projects.
| Name & Specification | Diameter | Thickness of plate | Legs | Weight | Height of silo body | Total height | Height of legs | Container quantity |
| 35t | 3.16m | 5 / 4 mm | 219 / 5.5mm | 4t | 4m | 8.2m | 4.2m | / |
| 50t | 3.16m | 5 / 4 mm | 219 / 5.5mm | 4.5t | 6.5m | 10.7m | 4.2m | / |
| 75t | 3.16m | 5 / 4 mm | 219 / 5.5mm | 4.6t | 8m | 12.2m | 4.2m | / |
| 100t | 3.16m/4.5m | 5 / 4 mm | 219 / 5.5mm | 5.5t | 10.7m | 14.9m | 4.2m | / |
| 150t | 3.16m/4.5m | 5 / 4 mm | 219 / 9mm | 8t | 15m | 19.2m | 4.2m | / |
| 200t | 4.5m | 6 / 5 / 4mm | 273 / 8mm | 12t | 11.5m | 15.7m | 4.2m | / |
| 300t | 5.5m | 8 / 6 / 4mm | 325 / 8mm | 17t | 8.7m | 12.9m | 4.2m | / |
| 400t | 5.5m | 8 / 6 / 5mm | 325 / 10cm | 21t | 12.2m | 16.6m | 4.2m | / |
| 500t | 6.8m | 10 / 8 / 5mm | 325 / 10mm | 28t | 13.5m | 17.7m | 4.2m | / |
