HZS series concrete batching plant

Description:

Release time:2026-08-21
Views:127

Product Details


 (25-75m³/h)The HZS stationary concrete batching plant is a fully automated system designed for efficient concrete production. Its modular structure allows for rapid installation and easy relocation.

Equipped with a high-performance twin-shaft mixer, the plant consistently produces a variety of concrete types with uniform quality. An integrated PC+PLC automatic control system ensures precise batching and real-time monitoring, delivering weighing accuracies within ±2% for aggregates and ±1% for cement and water.

Selecting the appropriate model depends primarily on your project's required concrete output. Smaller models like the HZS25 or HZS35 are cost-effective for rural or small municipal projects. In contrast, large-scale infrastructure such as high-speed rail hubs or major dams would require high-capacity models like the HLS120 or HLS180


Product Specs

Name of parametersHZS25HZS40HZS50HZS75
Theoretical productivity25m³/h35m³/h50 m³/h75 m³/h
Model of mixerJS500JS750JS1000JS1500
Mixing motor power18.5kw30kw2x18.5kw2x30kw
Cycle period72s72s72s72s
Volume of mixer500l750l1000l1500l
Aggregate max size≤80mm≤80mm≤80mm≤80mm
Suppose volume of cement silo - OPTIONAL2x100t2x100t3x100t3x100t
Capacity of batching machine800l1200l1600l2400l
Volume of batching machine3x4 m³3x4m³3x6 m³3x8 m³
Quantity of aggregate3333
Conveyor ability of aggregate belt100t/h150t/h200t/h250t/h
Max. Conveyor ability of screw conveyor40t/h40t/h80t/h80t/h
Unloading height1.6m3.8m4.0m4.0m
Total power of the plant55kw75kw105kw150kw
